In the fast-changing modern society, whether it is temporary living needs, flexible office space, or shelter in emergencies, there is a growing demand for fast, convenient, and reusable space solutions. Traditional construction methods are time-consuming, costly, and lack flexibility. YG portable expandable homes are an innovative modular building unit. Its core design lies in the “foldable” or “expandable” structure, which makes the house compact during transportation and convenient for standard container transportation (for example, a 40-foot container may be able to hold multiple folding units), thereby greatly reducing logistics costs. After arriving at the destination, the house can be unfolded or expanded to the preset size through simple operations, quickly forming a spacious indoor space. If you are also interested, please feel free to contact us for product information.
Portable Expandable Homes — Support Customization
| 20FT Basic Characteristics
|
External dimension (mm) | W6320*L5900*H2480(Side 2270) |
| Internal dimension (mm) | W6160*L5560*H2240(Side 2150) | |
| Folded state (mm) | W2200*L5900*H2480 | |
| Total mass (kg) | 2500 | |
| 30FT Basic Characteristics
|
External dimension (mm) | W6360*L9000*H2480(Side 2180) |
| Internal dimension (mm) | W6200*L8660*H2240(Side 2060) | |
| Folded state (mm) | W2200*L9000*H2480 | |
| Total mass (kg) | 3750 | |
| 40FT Basic Characteristics
|
External dimension (mm) | W6240*L11800*H2480(Side2180) |
| Internal dimension (mm) | W6080*L11540*H2200(Side2060) | |
| Folded state (mm) | W2200*L11800*H2480 | |
| Total mass (kg) | 4400 | |
| Smaller Fold Size
|
External dimension (mm) | W4820*L5900*H2480(Side2270) |
| Internal dimension (mm) | W4660*L5560*H2240(Side2150) | |
| Folded state (mm) | W700*L5900*H2480 | |
| Total mass (kg) | 1850 |
Compared with the traditional portable container house or simple portable shipping container house modification, YG portable expandable house provides larger interior space and a more comfortable living experience without sacrificing portability. Its rapid deployment capability and high degree of integration are also significant technical advantages.
Working Principle of Portable Container House:
The core working principle of the YG mobile portable expandable house is based on a sophisticated folding and support system. In the transport state, the side walls, end walls, and roof of the house are designed to be foldable or nested together and compactly fixed on the bottom frame.
When it is necessary to unfold, first fix the bottom frame, and then use the built-in hydraulic system (some large models) or simple mechanical devices/manual assistance to unfold the folded side walls and roof outward or upward until they reach the predetermined position. Subsequently, install or unfold the internal support structure (such as columns and beams) to firmly fix the entire house structure. Finally, connect the water and electricity pipelines and make a simple internal layout before use. The whole process is like a sophisticated Transformer, quickly transforming from a compact transport unit into a fully functional living or working space.
Advantages of Choosing YG Portable Expandable Homes:
- Significantly reduce costs: Compared with traditional buildings, the construction cost and time cost are greatly reduced. High transportation efficiency also saves costs. For scenarios that require temporary or rapid deployment of space, it is extremely cost-effective.
- Ultimate speed and efficiency: It can be put into use within a few hours, solving the urgent need for temporary space and greatly improving response speed and operational efficiency.
- Excellent space flexibility: It can quickly increase or decrease space units according to needs to cope with business expansion or adjustments. Its removability means that the asset is not a fixed investment and has higher liquidity.
- Environmental protection and sustainability: Factory prefabrication reduces the generation of waste materials in on-site construction, and the reusable and removable characteristics are also in line with the concept of sustainable development.
- Improved living/working experience: Good thermal insulation and sound insulation performance, as well as customizable interior decoration, provide a more comfortable and pleasant environment than simple portable container homes.
Portable Expandable Homes Price and Purchase Information
The price of YG portable expandable house is affected by many factors, including house size (such as 20-foot or 40-foot model), interior configuration (basic or luxury), degree of customization, purchase quantity, and transportation distance.
Typically, the price of a standard configuration YG portable expandable house unit ranges from a few thousand dollars to tens of thousands of dollars. The specific quotation needs to be determined according to your detailed needs. As a source manufacturer, YG provides factory-direct sales services, which means you can get more competitive prices and communicate directly with our technical team to ensure that the product fully meets your requirements.
To get an accurate quote or learn more about purchasing details, please contact us now. We will provide you with professional consulting services and provide the best solution based on your specific application scenario.
